Mustang Intelligent Vaporizer Sampling System®– Model 2

Gas Analysis Worksheet
Mustang Intelligent Vaporizer Sampling System®– Model 2
Product Details

The Mustang Intelligent Vaporizer Sample Conditioning System – Model 2 (MIV2®) is a patented technology, designed to vaporize liquid, providing a fresh sample to a continuous online analyzer. This system is designed with enhanced sample quality, through controlled vaporization, accumulation, and homogenization, accomplished through multiple stages. For the analyzer to meet it’s stated accuracy, the Mustang Intelligent Vaporizer Sample Conditioning System ensures the sample to the analyzer is stable.

Specifications
Maximum allowable working pressure
500 psig (35 bar) @ -360ºF (-218ºC)
Proportional temperature control range
0ºF to 200ºF (-18ºC to 93ºC)
Thermal cut-off
Opens at 230ºF (110ºC)
Port sizes
1/4” female NPT
Conduit connection
3/4” female NPT
Electrical enclosure classification
Class 1, Division 1 & 2, Groups C, D, T3 (CE Ex II 2 G Ex d II B T3 Gb Zones 1 & 2 Pending)
Wetted materials
Machined parts: 316 stainless steel/NACE compliant All other metal parts: stainless steel/NACE compliant; (other materials available upon request)
Input Supply Voltage
120 VAC, 800 Watts, 50/60 Hz, ± 10% 240 VAC, 800 Watts, 50/60 Hz, ± 10%
Features
Continuous gas flow design
Integral flow restrictor on inlet
NEMA 4X Enclosure
Dimensions
MIV2 Drawing
Benefits
Instantaneous vaporization of a liquid sample
Prevents post-vaporization hydrocarbon liquid dropout
Provides a homogenous sample
Provides an accurate and reliable representative sample to the gas chromatograph
Easy maintenance
Supplies samples, including composite and manual grab samples, to multiple analyzers
Dedicated software platform for operating, monitoring, trending, and reporting (see SoftView® Monitor)
Literature
Mustang Intelligent Vaporizer Sampling System Model 2 ATEX/IECEx Cut Sheet
